The RDA698/2700-1-SSM is an RFMAX Hi-Gain Dipole /  Flat Paddle Antenna for 698-2700 MHz 3G/4G/LTE cellular coverage with an articulating knuckle and standard SMA Male Connector. This blade, or paddle style antenna is designed for use with 3G/4G/LTE embedded cellular modems, access points, routers, gateways and small base station applications. The RDA698/2700-1-SSM covers all North American carrier legacy 3G bands, plus the 4G/LTE frequency ranges of 698-960, 1400-2170, 2300-2500 (Band 30 or 802.11 WiFi) and 2500-2690 MHz providing omnidirectional radiation with a gain of 1.0 - 2.16 dBi.

The blade style package offers a right angle swivel provided in black plastic with dimensions of 8.8 inches long (straight) x 1.2 inches wide It is supplied with an SMA Male connector which mates all standard cellular modems and gateways, or via a cable assembly to cellular modem modules.

FEATURES:

• 3G-4G/LTE Blade Style DiPole Antenna
• Operates at 698-960, 1400-2170, 2300-2500, and 2500-2690 MHz
• High-Gain & High Efficiency for passing carrier testing for TRP & TIS
• Articulating Knuckle & Standard SMA Male connector
• RoHS Compliant
